Promac Heavy Duty Mulcher

This robust, forest-rated machine delivers high production rates and a consistent mulch size. It is designed for operators working above ground level. Developed by in-house engineers working closely with customers, this line of heavy duty mulching heads for excavators features precision-manufactured tooling, rotors, bearing housings, shafts and drive systems which have been tried and tested on the rugged and demanding terrain of the Canadian west coast for over 10 years. Reliable, durable and easy to maintain, the Heavy Duty Mulcher is backed up by Promac’s renowned warranty, service and customer support.

Promac HDM Details

Standard Features
  • Suitable for heavy duty mulching applications
  • Powerful and efficient hydraulic piston motor
  • Available in 36, 48 and 60″ cutting widths
  • Multiple rotor and tooling options available
  • Heavy-duty, fully welded, structural frame
  • Suitable for a 13-30+ ton excavator
  • Optional features and customizations available
Optional Features
  • Carbide-faced tooling for longer wear in operations where contact with the ground is routine
  • High performance rotor drive kit for rotor speeds up to 3000 RPM
  • Variable displacement motor for faster rotor recovery and increased low speed torque
  • Custom colors available
Standard Specifications
HDM 36HDM 48HDM 60
Excavator Size (tons)13+20+22+
Cut Width36"48"60"
Approx. Weight2800lb3000lb3200lb
Motor size (cc)80107107
Motor typeBent axis pistonBent axis pistonBent axis piston
Flow Min (GPM)3545-5045-50
Flow pressure (PSI)400040004000
Tooling typeQuadQuadQuad
Tooling number242628
  • Land clearing
  • Forest fire prevention
  • Road development and maintenance
  • Pipeline development and maintenance
  • Trail development and maintenance
  • Transmission line development and maintenance
  • Railway development and maintenance
Custom Brackets

Every piece of equipment has a different attachment apparatus so one bracket ‘does not fit all.’ Promac offers a custom bracket manufacturing service for all of our Brushmulcher and Brushcutter customers. Tell us the make and model of your equipment and we will supply you with the design, manufacturing time and cost of a custom bracket that fits all of your needs. [showmodule id=”5232″]
